Note: This mount requires a roller fairlead bracket that comes with most of the winches out there.

• If your winch kit did not come with a fair-lead bracket you will need the following:
• For most winches with a 4-Hole 3.00" x 4.875" (STANDARD) KFI#100495
• For most winches with a 4-Hole 3.00" x 6.600" (WIDE) KFI#100695
• For WARN VRX or AXON winches with a 3.00" x 4.875" (STANDARD) KFI #101715

Features:

• 100% MADE IN USA
• Constructed of 3/16" steel
• Unlike all other mount competitors, our mounts are metal bead blasted before they are powder coated for the best possible finish prep
• Powder coated black for supreme durability
• Very easy to install
• Roller fairlead, winch, and fairlead bracket not included

COMPATIBLE WINCHES:

• KFI: ST17 / S2000 / A2000 / A2500-R2 / A3000 / U45-R2 / U45w-R2 / SE25 / SE35 / SE45-R2 / SE45w-R2
• KFI: AS-50 / AS-50w
• WARN: A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce
• WARN: VRX 25 / VRX 25-S / VRX 35 / VRX 35-S / VRX 45 / VRX 45-S
• WARN: AXON 35 / AXON 35-S / AXON 45RC
• WARN: AXON 45 / AXON 45-S / AXON 55 / AXON 55-S
• WARN: RT15 / RT25 / RT30 / XT15 / XT25 / XT30
• WARN: Vantage 2000-3000lbs / Provantage 2500-3500lbs
• WARN: RT40 / XT40
• WARN: Vantage 4000lbs / Provantage 4500lbs
• RAMSEY: ATV2500 / ATV3000
• SUPERWINCH: Terra25 / Terra35 / Terra 45 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV
• MILE MARKER: PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
• MASTER LOCK: 1500lbs #2955AT (Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF)
• CYCLE COUNTRY: Work Power 1500 and 2500 / Powermax 2500 and 3500
• BADLAND: 2-Hole Winches
• BADLAND: Standard Winches
• BADLAND: WIDE Winches
• CHAMPION: 2-Hole Winches
• CHAMPION: Standard Winches
• CHAMPION: WIDE Winches
• CHAMPION: 14001 and 14061
• SMITTYBILT: XRC 2.0 (Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF.Listed models come with incorrect ATV roller fairleads)
• SMITTYBILT: XRC 3.0 / XRC 4.0
• XGEAR:  X3000 / X4000 (4-Hole Standard 3.00" x 4.875" bolt pattern)
• KEEPER CORP. TRAKKER: KT2500 / KT3000 / KT2500C / KT3000C / KT4000 / KT4000C
• VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Hardcore Series) (All with 3.00" x 4.875" bolt pattern mount-up; All with 3.00" x 6.600" bolt pattern mount-up)
• Traveller: 1078311
• Traveller: 1078088 / 1078302 (Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF)

Possibly many others with the below standard mounting patterns:

• 4-Hole (3.00" x 4.875" bolt pattern with rollers that are 4.875" bolt pattern)
• 4-Hole WIDE (3.00" x 6.60" bolt pattern with rollers that are 6.600" or 6.000" bolt pattern)
• 2-Hole (3.10" with rollers that are 4.875" bolt pattern)
